MF1500 Frozen Block Meat Flaker

MF1500 Frozen Block Meat Flaker

Catalog No.: 2501
Price: Ask for quote

Description

Features:

Stainless steel construction
Built-in loading table

Cutting drum is enclosed with electrical safety guard
Voltage: 230 V / 60 Hz / 3 Ø
Compressor: 2 HP required (Supply by customer)
Motor: 15 HP
Fits 400 lb buggy
O/A dims.: 97 x 45 x 52" H
Maximum product size capacity: 27 x 20 x 9" thick
Production capacity: 30,000 lb per hour depending on the thickness of the flake
Flaking thickness available: .20" (5mm), .63" (16mm), 1.22" (31mm)
Product temperature: 10.4°F - 21.2°F
Lockout/Tagout On/Off switch

Analog control:
Stop switch
Timer
Forward/reverse function
Automatic/manual feed blocks with pneumatic ram (80 PSI pressure)

Flakes tempered or frozen blocks of meat, poultry, or other products to assist in further processing.

Option:
Electrical: 460V / 60Hz / 3Ph
Additional size flaking knives: (6 per set)
Spare parts kit

Videos

MF1500 Frozen Block Flaker Young Coconut Block Demo
Butcher Boy MF-1500 Frozen Block Meat Flaker - Frozen Cow Stomach Block Demo
Butcher Boy MF1500 Frozen Block Meat Flaker - Frozen Pork Block Meat Demo
Butcher Boy MF1500 Frozen Meat Block Flaker - Frozen Chicken Meat Block Demo
